Rev Electrix Cellpro 10XP - Page 18

18

1.0C
(where C = pack’s capacity)

2.0C

3.0C

STORE
(to charge or discharge pack to 50% capacity; optimum for long-term storage)

(Return to manual charge current settings at 0.1A)
Note: The charger’s AUTO charge fuel gauge tables are optimized for Lithium Cobalt batteries. If you are
charging Lithium Manganese batteries, AUTO charge modes may not be accurate. Manual current
settings are recommended when charging Lithium Manganese batteries. Use the CCS to assign the
appropriate fuel gauge table to your presets to improve the accuracy of AUTO charge mode.

To change the chemistry:
a.
Press and hold the MODE button
, then release it when the display changes to this:
Choose Chemistry
Hold for More
Note: If you hold the MODE button down longer, you’ll see
Show Help Screen
, etc (described
below).
When you release the
MODE button
, you’ll see the chemistry setting:
Choose Chemistry
[chemistry] [BAL] [voltage]
b.
Press and release the MODE button
until you see the chemistry you want. Choices are:
Chemistry/Charge Mode
Description
LiPo BAL 4.20V
LiPo Balance Charge to 4.20V per cell
LiPo BAL 4.22V
LiPo Balance Charge to 4.22V per cell
LiPo BAL 4.10V
LiPo Balance Charge to 4.10V per cell
A123 BAL 3.65V
A123 (or LiFe) Balance Charge to 3.65V per cell
NiCd 8mV Fall Bk
NiCd Unbalance Charge, Peak Detect, 8mV Fallback
NiMH 5mV Fall Bk
NiMH Unbalance Charge, Peak Detect, 5mV Fallback
LEAD 6V
Lead Acid Charge to 6V
LEAD 12V
Lead Acid Charge to 12V
LEAD 18V
Lead Acid Charge to 18V
LEAD 24V
Lead Acid Charge to 24V
LiPo 1sU 4.20V
LiPo Unbalance Charge, 1s to 4.20V
LiPo 2sU 8.40V
LiPo Unbalance Charge, 2s to 8.40V
A123 1sU 3.65V
A123 (or LiFe) Unbalance Charge, 1s to 3.65V
A123 2sU 7.30V
A123 (or LiFe) Unbalance Charge, 2s to 7.30V
A123 3sU 10.95V
A123 (or LiFe) Unbalance Charge, 3s to 10.95V
A123 4sU 14.60V
A123 (or LiFe) Unbalance Charge, 4s to 14.60V
A123 5sU 18.25V
A123 (or LiFe) Unbalance Charge, 5s to 18.25V
A123 6sU 21.90V
A123 (or LiFe) Unbalance Charge, 6s to 21.90V
A123 7sU 25.55V
A123 (or LiFe) Unbalance Charge, 7s to 25.55V
A123 8sU 29.20V
A123 (or LiFe) Unbalance Charge, 8s to 29.20V
A123 9sU 32.85V
A123 (or LiFe) Unbalance Charge, 9s to 32.85V
A123 10sU 36.50V
A123 (or LiFe) Unbalance Charge, 10s to 36.50V
A123 11sU 40.15V
A123 (or LiFe) Unbalance Charge, 11s to 40.15V
A123 12sU 43.80V
A123 (or LiFe) Unbalance Charge, 12s to 43.80V

To get help using the Cellpro 10XP:
Press and hold the MODE button
, then release it when the
display changes to this:
