29
The Remote Control replicates the controls found on the device
Operating Frequencies
Operating Range Distance
0 to 25m at horizontal
0 to 18m at +/- 30 degree angle
from the horizontal.
Net Charge @ 500Ω Foot: [0 - 0.006]mC Body: [0.001 - 0.002]mC
Maximum Phase Charge @ 500 Ω Foot: 41µC Body: 15µC
Maximum Current Density Foot: 0.023 mA/cm² Body: 0.082 mA/cm²
Maximum Power Density @ 500Ω
Foot: 0.55 mW/cm² Body: 1.64 mW/cm²
Burst Mode: a. Pulses per burst Foot: 11 - 256 Body: 49 - 154
b. Bursts per second
Foot: 0.1 - 0.5 Body: 0.2 - 0.5
c. Burst duration
Foot: 1.9 - 8.4s Body: 1.9 - 6.5s
d. Duty Cycle Foot: 0.56 – 0.87 Body: 0.66 – 0.87
ON Time Foot: 1.92 - 8.34s Body: 1.92 - 6.52s
OFF Time
Foot: 1 - 1.5s Body: 1s
Disposal: At the end of product life do not throw this product into normal household garbage, but
take it to a collection point for the recycling of electronic equipment.
1718_IFU01_7244012.indd 29 27/03/2015 10:04
