28
Name of product REVITIVE
Model RIX
Weight 1.725Kg
Dimensions
Ø360mm x 75mm (isorocker enabled)
Ø360mm x 100.5mm (isorocker disabled)
Power Consumption 5W
Power Source:
AC Adaptor – UL (Underwriters Laboratories)
Safety Mark
Input
Output
100-240V, 50/60Hz, 0.18A.
5.0Vdc, 1.0A
Output Specifications:
Waveform Pulsed Symmetrical Biphasic
Shape Rectangular and bipolar
Maximum Output Voltage: @500Ω Foot: 32V Body: 20V
@2kΩ
Foot: 118V Body: 95V
@10kΩ
Foot: 169V Body: 138V
Maximum Output Current: @ 500Ω Foot: 64mA Body: 40mA
@2kΩ
Foot: 59mA Body: 48mA
@10kΩ
Foot: 17mA Body: 14mA
Pulse Duration:
Foot: 370µs and 940µs Body: 370µs
Frequency:
Foot: 20 to 53Hz, Body: 35 to 46Hz
Technical Specifications
1718_IFU01_7244012.indd 28 27/03/2015 10:04
