1
Take the bed out of the box, put it on
the slat base, do not install any legs.
Keep the bed folded.
3
Turn over the bed. Install the middle
stabilizer bracket as shown.
(*Optional parts are needed. )
2
Connect the hand control and secure it with the
connector lock.
Make sure the AC power cord is not connected
to the AC power source.
Please connect the DC power cord to the power
supply, and connect the AC power cord.
Pull the AC power cord towards the direction of
the AC power source through either the bottom
or the side of the bed frame.
—07—
Customer Service Toll Free: 1-844-696-6886 Email: motoservice@hhcusacorp.com
HEADBOARD
Hand
Control
Hand
Control connector
AC Power Cord
Power Supply
DC Power Cord
Metal Frame
Of The Bed
HEADBOARD
Slat Base
ST4.2×16
Screw
HEADBOARD
A
D
C
B
(1) (4)
ST4.2×16
Screw
Middle Stabilizer
Bracket
STABILIZER BRACKETS COMPONENTS (OPTIONAL)
X V
