HEAD BOARD
8mm ID
Washer
M8×16
Bolt
ST4.2×16
Screw
(2)
(1)
(4)
ST4.2×16
Screws
Stabilizer
Brackets
STABILIZER BRACKETS COMPONENTS
(4)
M8×16
Bolts
(4)
8mm ID
Washers
Socket
Wrench
S V
U
W
T
—10—
Customer Service Toll Free: 1-844-696-6886 Email: motoservice@hhcusacorp.com
DONE!
9
Lift the head of the bed by hand control. Install the two stabilizer brackets as shown.
(*Optional parts are needed. )
HAND CONTROL INSTRUCTIONS
This button lifts the head section of the foundation.
This button lowers the head section of the foundation.
Lift Head
Lower Head
ADJUST
