—11—
Headboard brackets are optional and not included.
A 1/2” (13mm) socket wrench and 1/2” (13mm) wrench are required to complete the installation.
a) Align the headboard bracket slot with the mounting holes
on the bed frame. DO NOT OVERTIGHTEN. Too much
force may damage the thread.
b) The headboard bracket has 2 adjustable slots to
accommodate any frame type. Use the (2) M8×16 bolts and
(2) 8mm ID washers to secure the bracket. Make sure the
bolts are tight.
a) To put the T-Bracket and headboard bracket together, you
will need (2) M8×16 bolts and (2) M8 nuts. Slip the bolts
through the holes from T-Bracket to headboard bracket with
the head of bolt facing outward. Use the 1/2” (13mm) socket
wrench and 1/2” (13mm) wrench to tighten the bolts.
Repeat Step 1 to 2 to install the other headboard bracket on
the other side of the bed.
ion
OPTIONAL HEADBOARD BRACKET COMPONENTS
(2)
Headboard Brackets
(2) T-Brackets (8) M8
×
16 Bolts (4) M8 Nuts (4) 8mm ID Washers
L M N O P
Customer Service Toll Free: 1-844-696-6886 Email: motoservice@hhcusacorp.com
