Parts List
All electronics and components that need to be installed are located in boxes under the foundation or
attached to the frame. Before discarding the packing materials, ensure that all the parts are accounted for.
Part Y and part Z are the parts that need to be removed from the bed frame.
PARTS LIST
Hand Control
AC Power Cord Leg(1³⁄5")
Power Supply with
Battery Backup Box
(1) (1) (1) (2)
B
Frame
(1)
A C D E
DESCRIPTION
QUANTITY
CODE
9V
9V
9V
6LR61
Alkaline Batteries
(Optional)
Leg(11³⁄8")
(6) (1)
F G
DESCRIPTION
QUANTITY
CODE
Mattress Retainer
Bar
(2 for K/CK)
Locking Pin
1 (2 for K/CK) 1(2 for K/CK)
Y Z
DESCRIPTION
QUANTITY
CODE
Red Plastic
Safety Clip
Customer Service Toll Free: 1-844-696-6886 Email: motoservice@hhcusacorp.com
