Revolabs Executive HD ™ Indicator LEDs
The following tables show activities associated with the various states shown by the LEDs:
Equipment Use
Microphone LED
Base Station
Channel LEDs
Meaning
Microphone in Charger
Base
Solid RED
OFF
Charging in Progress
Solid GREEN
OFF
Charging Complete
Microphone not in
Charger Base
OFF
OFF
Microphone powered OFF or
battery discharged
Two RED flashes
every 1.5 seconds
Two RED flashes
every 1.5 seconds
Microphone paired and muted
GREEN flash every
1.5 seconds
GREEN flash every
1.5 seconds
Microphone paired and ―live‖
Solid RED
Solid RED
Pairing mode or confirmation of
powering-down.
Alternating slow
GREEN and RED
Alternating slow
GREEN and RED
Microphone or channel not
paired
YELLOW flash
alternating with
GREEN
GREEN Flashing
Microphone low battery
(mic live)
YELLOW flash
alternating with two
RED flashes
RED Flashing
Microphone low battery
(mic muted)
Alternating RED,
YELLOW, GREEN
OFF
Searching for a connection, or
out of radio range. The
Microphone will try to re-
establish the link for about 15
minutes, and then turn off
automatically.
Rapid RED flashes
continuing for more
than a few seconds
OFF
Radio congestion – it is not
possible to make a radio
connection because there are
already too many nearby users,
or there is heavy radio
interference. Possibilities
include some types of digital
wireless devices or other
Revolabs installations.
Groups of five rapid
RED flashes
OFF
Unit is faulty. Contact your AV
service provider for advice.
