Charger specications
For battery types Lithium Polymer (1s to 4s balanced, 1s to 2s unbalanced)*
Lithium Ion (1s to 4s balanced, 1s to 2s unbalanced)
Lithium Manganese (1s to 4s balanced, 1s to 2s unbalanced)
A123 (2s to 4s balanced, 1s to 5s unbalanced)*
NiCd (1s to 12s)
NiMH (1s to 12s)
6V and 12V Lead Acid batteries
Pack capacity 5mAh to 32Ah (charge time limited to maximum of 8 hours)
Input voltage 10 to 16VDC, reverse polarity protected
Input current 5A maximum
Power conversion 125kHz switcher operating at 90% efciency
Output current Up to 4A
Cell balancing To within 5mV for 2s to 4s LiPo, Li-Ion, Li-Mn or A123 packs
Voltage calibration Cell voltage measurements are factory calibrated to a standard
traceable to NIST; calibration is to ±6mV
Current calibration Charge current is factory calibrated on a 4A standard; calibration is to
±1mA
Measurement accuracy Voltage: ±6mV
Charge current: ±1%
Capacity added to pack: ±1%
Percent capacity (“Fuel”): ±5%
Serial data output 19.2kbps, 8 bits, 1 start bit, 1 stop bit, no parity
*charger can be used with balanced 2s to 4s packs having a node connector (an
appropriate FMA adapter may be required)
Working with les
n To save a single preset: In the Presets tab, select the preset, then File > Save Preset n to
File...
.
n To load a single preset: In the Presets tab, select the preset, then File > Open File to
Preset n...
.
n To back up all User Presets: File > Backup User Presets... .
n To restore User Presets: File > Restore User Presets... .
n To back up all Library Presets: File > Backup Library Presets... .
n To restore all Library Presets: File > Restore Library Presets... .
CCS le types
.pst Single preset le .psk User Presets backup le
.lpb Library Presets backup le .cp4 Charge graph le
