Table 8. Control Board Operation
CONTROL SIGNAL &
MODE
OPERATION TOTAL KW BOARD ACTION
W
HEAT
ON
10
Stage 1 Heat on immediately
HEAT Blower on after 3 second delay
Stage 2 heat on after 10 second delay
12
Stage 1 Heat on immediately
HEAT Blower on after 3 second delay
Stage 2 heat on after 10 second delay
15
Stage 1 Heat on immediately
HEAT Blower on after 3 second delay
Stage 2 heat on after 10 second delay
Stage 3 heat on after 20 second delay
17
Stage 1 Heat on immediately
HEAT Blower on after 3 second delay
Stage 2 heat on after 10 second delay
Stage 3 heat on after 20 second delay
20
Stage 1 Heat on immediately
HEAT Blower on after 3 second delay
Stage 2 heat on after 10 second delay
Stage 3 heat on after 20 second delay
Stage 4 heat on after 30 second delay
23
Stage 1 Heat on immediately
HEAT Blower on after 3 second delay
Stage 2 heat on after 10 second delay
Stage 3 heat on after 20 second delay
Stage 4 heat on after 30 second delay
OFF -
Heat stages off immediately
Blower turns off after 15 second delay
W & Y
AUX HEAT
ON
10
Stage 1 Heat on immediately
Blower on after 3 second delay (HEAT or COOL speed, whichever is greater)
Stage 2 heat on after 10 second delay
12
Stage 1 Heat on immediately
Blower on after 3 second delay (HEAT or COOL speed, whichever is greater)
Stage 2 heat on after 10 second delay
15
Stage 1 Heat on immediately
Blower on after 3 second delay (HEAT or COOL speed, whichever is greater)
Stage 2 heat on after 10 second delay
Stage 3 heat on after 20 second delay
17
Stage 1 Heat on immediately
Blower on after 3 second delay (HEAT or COOL speed, whichever is greater)
Stage 2 heat on after 10 second delay
Stage 3 heat on after 20 second delay
20
Stage 1 Heat on immediately
Blower on after 3 second delay (HEAT or COOL speed, whichever is greater)
Stage 2 heat on after 10 second delay
Stage 3 heat on after 20 second delay
Stage 4 heat on after 30 second delay
23
Stage 1 Heat on immediately
Blower on after 3 second delay (HEAT or COOL speed, whichever is greater)
Stage 2 heat on after 10 second delay
Stage 3 heat on after 20 second delay
Stage 4 heat on after 30 second delay
