Bestuckung:
(ohne
Dolby-Steckkarte)
65
Integrierte Schaltungen
(1C),
63
Transisto-
ren, 2
Dioden-Matrizen
(91
Dioden),
42
Dioden,
19
Abstimm-Doppeldioden,
3
Briickengleich-
richter,
7
Sieben-Segment Anzeigen.
Stromversorgung:
umschaltbar:
1
00,
1
20,
1
40,
200, 220,
240
V
50... 60
Hz, 40 Watt
Netzsicherung:
100 ... 140 V;
0,5
AT
200
... 240
V; 0,25
AT
Stromversorgung
des
elektronischen
Speichers
bei
Netzausfall
durch drei
Alkaline-Batterien
a
1,5
V(R6,
UM3, Size AA).
Gewicht:
(Masse)
12
kg
Abmessungen:
B
X H
X
T
=
452 x
1 51 x 348
mm
Composants:
(sans
circuit Dolby)
65
circuits
integres
(1C),
63
transistors,
2 matrices
a
diodes
(91
diodes),
42
diodes,
19 double-diodes
a
capacite,
3 redresseurs^en
pont
et
7 indicateurs sept
segments.
Alimentation:
Commutable:
1
00,
1
20,
1
40,
200, 220,
240 V
50 ... 60 Hz, 40 watts
Fusible secteur:
100..
.
140
V:
0,5
AT
200..
.
240
V:
0,25
AT
En cas de coupure secteur, alimentation se-
condaire de la memoire
electronique
par
3
piles
alcalines de
1,5
V(R6, UM3, Size AA).
Poids:
12 kg
Dimensions:
L
X H X P
=
452 X 1
51 X 348
mm
Component parts:
(without
Dolby
circuit
board)
65
integrated
circuits
(1C), 63
transistors,
2
diode matrizes (91
diodes), 42 diodes,
1
9
vari-
able
capacity
double diodes,
3
bridge rectifiers,
7
seven-segment
displays.
Electric
Current Supply:
Voltage
selector
for;
1
00,
1
20,
1
40,
200, 220,
240
V
50
... 60 Hz, 40 watts
Main
fuse:
100 ... 1 40
V:
0.5 AT
200 ...
240
V:
0.25 AT
In case of
power line failure,
the
current supply
for the
electronic
memory
unit is maintained by
three 1.5 V
alkaline-batteries (R6,
DM3,
Size
AA).
Weight:
1 2 kg
(26
lbs
7 ozs)
Dimensions:
W X H
X
D=
452 X 151
X
348
mm
(1
7.8
X
6
X
1
3.7 inches)
Anderungen vorbehalten. Sous reserve
de modification.
Subject to
change.
1-6
