Revox G36 Service Manual

INDEX ORDER
N°
PART DESCRIPTION SERIES Qu Ind
III
I II III
Carrying Case
1.736.825 Case Bottom Complete x x x 1
1.736.828-01 Case Bottom x x x 1 7001
1.736.828-03 Rubber Washer (Case Bottom Mount) x x x 4 7008
21.01.0458 Machine Screw (Case Bottom Mount) x x x 4 7009
23.01.1043 Washer for Case Bottom Mount x x x 4 7010
1.736.830 Case top Complete x x x 1 7002
1.736.850-02 Latch Case Top x x x 2 7003
1.736.832 Case Middle Section Complete x x x 1 7004
1.736.836 Rear Panel Cover Snap-fit x 1 7005
1.736.837 Rear Panel Cover, Hinged, including Frame x x 1 7006
1.736.832-05 Case Feet x x x 4 7007
1.736.834 Chassis Mounting Bracket x x x 2 7011
20.22.7306 Mounting Bracket Screw x x x 16 7012
1.736.832-04 Loudspeaker Lattice (Trapezoid) x 1 7013
1.736.832-08 Loudspeaker Lattice (Rectangular) x x 1 7014
33.03.0101 Carrying Handle Mounting Bracket x x x 1 7015
28.99.0106 Rivet, Tubular x x x 2 7016
1.736.501-04 Washer x x x 2 7017
33.03.0102 Carrying Handle x x x 1 7018
21.01.0455 Machine Screw M 4x8 (Chassis to Bracket) x x x 6 7019
Top Plate
1.736.851 Top Plate Complete x x 7021
Top Plate of Series I to be replaced with Top Plate
1.736.851 and Counter 1.736.502-15
x 7020
21.02.3375 Machine Screw M 3x12, Oval Head, for Mounting of
Top Plate
x x x 6 7022
1.736.853 Plastic Cover for Pressure Roller x x 1 7024
1.736.500-15 Plastic Cover for Pressure Roller x 1 7025
1.736.500-13 Plastic Head Cover (without Name Plate) x x 1 7026
21.02.3356 Machine Screw M 3x10, Oval Head x x 2 7028
43.02.0101 Revox Name Plate x x x 2 7029
1.736.855 Plastic Head Cover (with Name Plate) x 1 7027
1.736.500-04 Grey Plastic Knob (transparent) x x x 4 7030
1.736.500-10 Felt Washer x x x 4 7031
1.736.861 Grey Plastic Knob Colour 1035 x x 4 7032
1.736.861 Grey Plastic Knob Colour 6760 x 4 7033
1.736.791-01 Push Button Red x x x 2 7034
1.736.790-02 Push Button Black x x 2 7035
1.736.790-02 Push Button Grey x 2 7036
1.736.851-02 Escutcheon Plate x x x 1 7041
1.736.851-03 Escutcheon Plate, Push Buttons x x x 1 7042
1.736.180-01 VU – Meter x x x 2 7128
1.736.181 VU – Meter Mounting Board (Paxolin) x x x 1
1.736.180-03 Cover, VU – Meter x x x 2 7129
1.736.180-02 Tubular Spacer x x x 8 7130
51.02.0101 Pilot Lamp 7V / 0.1 A x x x 4 7131
1.736.255 Lampsocket Complete (without lamp) x x x 2 7132

Revox G36 Specifications

General

Signal to Noise Ratio	60dB
Heads	3 (Erase, Record, Playback)
Inputs	Microphone, Line
Outputs	Line
Type	Reel-to-reel
Track System	2-track
Frequency Response	30Hz to 20kHz
Reel Size	Up to 10.5 inch
Tape Speed	3.75, 7.5, 15 ips
