INDEX ORDER
N°
PART DESCRIPTION SERIES Qu Ind
III
I II III
B
Capstan Drive Assembly
1.736.125 Capstan Drive Assembly Without Head Support
50Hz
x x x 1
1.736.126 Capstan Drive Assembly Without Head Support
60Hz
x x x 1
1.736.120 Capstan Drive Assembly Without Head Support
7.5/15 ips 50 Hz 4/8 Pol
x 1
1.736.122 Capstan Drive Assembly Without Head Support
7.5/15 ips 50 Hz 6/12 Pol
x 1
01 22.01.8040 Hexagon Nut M4 x x x 4
02 1.736.125-01 Threaded Mounting Stud x x x 4 7091
03
Capstan Bearing Plate (see section
C)
04 1.736.136 Coupling Strip for Screw Mounting
(for motor with 2 coupling pins)
x x x 2 7090
21.01.0355 Machine screw for above (M 3x8) x x x 2
04 1.736.125-02 Coupling Strip, Push-On type
(for motor with 4 coupling pins)
x 4
05 1.736.134 Flywheel Complete
(for Motor with 2 Coupling Pins)
x x x 7085
05 1.736.135 Flywheel Complete
(for Motor with 4 Coupling Pins)
x 1
06 1.736.128-07 Washer x x x 1
07 37.01.0110 Spring Washer x x x 1
08 22.01.5060 Hexagon Nut x x x 1
09 1.736.138-02 Coupling Pin (for Motor with 2 Coupling Pins) x x x 2 7089
09 1.736.140-02 Coupling Pin (for Motor with 4 Coupling Pins) x 4
2 different types of capstan motors are used in the
G36
Old version: 2 coupling pins and strips with screw
mounting.
New version: 4 coupling pins and strips with push-on
mounting.
The coupling pins have to be ordered separately.
10 1.060.060-01 Capstan Motor 50 Hz OLD x x x 1 7079
10 1.736.141 Capstan Motor 50 Hz NEW x 1
10 1.736.140-01 Capstan Motor 60 Hz OLD x x x 1 7080
10 1.736.142 Capstan Motor 60 Hz NEW x 1
10 1.736.140-05 Capstan Motor 50 Hz 7.5/15 ips 4/8 pol x 1 7081
10 1.736.141 Capstan Motor 50 Hz 7.5/15 ips 6/12 pol x 1
11 1.060.052-01 Motor Housing x x x 1
12 21.01.0455 Machine Screw M 4x8 x x x 4 7092
