Revvi ABT-E250 - Essential Technical Parameters; Vehicle Specifications; Motor Specifications; Control System Parameters

Essential Technical Parameters
1. Vehicle
-Bike weight: 23kg
-Maximum load (weight):75kg;
2. Motor
-Type: DC, with brush;
-Rated continuous output power: P=250W;
-Rated speed: 275±7.5%rpm;
-Rated voltage: 24V;
-Rated output torque: 1.21 (N.m)
3. Controls
-Rated input voltage: 24V;
-Input voltage range: 20~28V;
-Input current without load:≤115MA；
-Max. output current of the motor: 30±1A;
-Under-voltage protection (Vqn) :20±0.5V;
-Max. conduction value: ≤95% (with the output current of
the control<2A);
-Starting voltage of handlebars: ≥1.4V；
-Protection voltage of the handlebars: ≤1.8V;
4. Charger
-Input: 100-240 VAC, frequency 50/60 Hz, input current:
1.8A Max;
-Output : 24V DC 1.5A
5. Batteries
-Size 152*65*94 mm;
-Type: Lead Acid Battery, 2×12V, 10AH.
