Assembly
Your Revvi arrives almost completely assembled, making it easy to
start riding. The only assembly required is to attach the handlebars.
All cables and controls already hooked up to the bike, so attaching
the handlebars is easy:
1. Using the 6mm Allen key attach the lower parts of the
handlebar clamps to the top of the forks. Do not tighten
until the handlebars are in place!
2. Place the handlebars into position in the lower clamps.
Take care to get the handlebars centered side so side, and
set in your desired upright position.
CAUTION Be careful not to lean the handlebars too far
forward or backward as this will affect the bike’s handling
and comfort of the ride.
3. Place the top parts of the clamps in position over the
handlebars and tighten the four bolts securely to 18-
26N.M. DO NOT OVERTIGHTEN.
4. Now tighten the two bolts holding the handlebar risers
to the forks to 18-26N.M. DO NOT OVERTIGHTEN.
