14
for LCD instruments
The fuel gauge only works when the ignition is switched on. The pointer of the display shows the fuel level. Reserve, tank symbol changes from white to red, a
warning appears in the display. From the red area there are still approx. 9 liters in the tank, at approx. 7.5 liters the reserve lamp then also lights up and below 5
liters a message 'please refuel' appears. For refueling, see page 31
Fuel gauge
1
2
3
4
5
1: < 2 Liters / 0,52 Gallons ~ 0%
2: 9 Liters / 2,4 Gallons ~ 25%
3: 18 Liter / 4,75 Gallons ~ 50%
4: 26 Liters / 6,9 Gallons ~ 75%
5: > 32 Liters / 8,5 Gallons ~ >90%
Max. tank volume: 38 Liter / 10 Gallons
T
Functions and settings
