Page 13 of 55
ILLUSTRATED PARTS MANUAL:
FLOWLINE COMB & WIRE
BINDER RANGE
MODEL CB405E
Part No Description Qty Comments
A55207 Mobile Jaw Assembly 1
A55216 Quadrant Gear RH 1
A55217 Quadrant Gear LH 1
BSH78 Oilite Bearing 1
BSH79 Oilite Bearing AL1824 1
D000431 Footswitch Decal 1
D47010 13T Gear 2
D55050 Comb Binder Die Plate 1
D55051 Comb Binder Stripper Plate 2
D55053 Spacer Block 1
D55055 Margin Guide 1
D55056 Spacer Washer 6
D55062A Side Frame LH 1 Made from D55062A
D55065 Punch - Individual 21
D55066 Punch Selector 3
D55072 Gear Shaft Long 1
D55073 Gearbox Top Casing 1
D55074 Gearbox bottom casing 1
D55076 Comb Opening Drive Plate 1
D55077 Comb Opening Finger Plate 1
D55078 Clamp Plate 1
D55079 Comb Opening Base Plate 1
D55081 Punch Handle Side Piece LH 1
D55083B Wire Closing Jaw Fixed 1
D55084 Punch Handle Side Piece RH 1
D55085 Handle Grip Long 1
D55087 Die Support Block 1
D55088 Comb Opening Drive Shaft 1
D55091 Comb Opening Clamp Spring 2
D55101 Handle Lock Cam LH 1
D55102 Handle Lock Cam RH 1
D55108 Margin Adjuster Screw 1
D55109 Margin Adjuster Thumb Wheel 1
D55110A Top Cover 1
D55111A Bottom Casing 1
D55112A Document Measurer 1 Supplied as part of A55173B – See Issue 19
D55112C Document Measurer 1 US Variant only – See Issue 16. Supplied as part of A55173I.
– See Issue 19
D55113 Back Stop Slider 1
D55115A Side Frame RH 1 Made from D55115
D55117 Comb Open Stop LH 1 Supplied as part of A55173A and A55173I – See Issue 19
D55118 Comb Open Stop RH 1 Supplied as part of A55173A and A55173I – See Issue 19
D55119 Comb Open Stop Plunger 1 Supplied as part of A55173A and A55173I – See Issue 19
D55123 Rubber Foot Back/Top 2
D55124 Wire Closing Spring 2
D55125 Document Support/lid 1
D55127 Comb Opening Knob 2
D55128 Wire Closing Cover 1 To S/No A713322 – See Issue 15
D55128P Wire Closing Cover Printed 1 From S/No A713323 – See Issue 15
D55130 Clippings Tray 1
D55131 Comb Opening Knob Spring 2
D55132 Comb Opening Stop Extension 1
D55133A Infill Panel 1 Supplied as part of A55173A – See Issue 19
To Next Page
