ILLUSTRATED PARTS MANUAL:
FLOWLINE COMB & WIRE
BINDER RANGE
D55133G Infill Panel 1 US Variant only – See Issue 16. Supplied as part of A55173I.
– See Issue 19
D55135 Punch Button 1
D55136 Punch Button Spring 1
D55138 Punch Selector Spring 3
D55139 Punch Selector Switch R 1
D55140 Punch Selector Switch M 1
D55141 Punch Selector Switch L 1
D55148 PCB Activation Cam 1
D55149 Comb Opening Stop Spring 1 Supplied as part of A55173A and A55173I – See Issue 19
D55155 Pull Plate 1
D55156 Punch Retainer 1
D55159 Document Measurer Spring 1 Supplied as part of A55173A – See Issue 19
D55162 Motor Pinion 1
D55163 Gear Shaft Short 1
D55166 Comb Open Stop Switch Mech Cover 1 To S/No A765520 – See Issue 18
D55189 Compound gear 34/13T 1
D55190 Compound gear 41/10T (Plastic) 1 To S/No A678190 Replaced by D55241/PLN29 – See Issue 5
D55191 Spur Gear 29T 1
D55192 Spur Gear 13T 2
D55193 Motor Support Bracket 1
D55194 Hex Spindle for gearbox 1
D55195 Hexagon Spindle 1
D55198 Buffer 2
D55199 Knob retaining clip 2
D55200 Fixed spindle 2
D55202 Rubber Foot - L Shape 2
D55203 Rubber foot – front 2
D55211 Wire Link no adjuster LH 1
D55212 Wire Link no adjuster RH 1
D55213 Punch Switch Insulation collar 1
D55215 Compound Gear 1
D55219 Motor insulator 1
D55220 Gearbox 1
D55225 Foot Pedal Socket and Lead 1
D55226 Wires - Cap to PCB 1
D55228 Push Plate 1
D55230 Handle Lock Spindle 1
D55236 Gear Box Shaft Retainer 1 See Issue 3
D55240 Compound Gear 41/10T (Sintered) 1 See Issue 12
D55241 Compound Gear 41/10T (Metal) 1 From S/No A678191 to A710068 See Issues 5 and 12
D55242 Thermal Fuse Assembly 1 From S/No A670764 to A694089 See Issues 4 and 11
D55246 Wires – Cap to PCB – 120v 1 US Variant only – See Issue 16
D55247 Ribbon Cable Bridge Piece 1 From S/No A721022 – See Issue 14
D55248 120v – Cap Insulator 1 US Variant only – See Issue 16
D55249 PCB Switch Insulator 1 US Variant only – See Issue 16
D55250 Cap Insulator End Piece 1 US Variant only – See Issue 16
D55252 Motor Insulator - Lower 1 US Variant only – See Issue 16
D55270 Fan Unit Bracket 1 US Variant only – See Issue 16
D55271 Retaining Plate 1 US Variant only – See Issue 16
D55272 Rivet Washer Plate 1 US Variant only – See Issue 16
PEG93 6 x 50mm heavy duty spirol pin 3
PEG95 1/8 x 3/8" medium duty spirol 21
PEG97 6mm dia x 16mm long dowel pin 2
PLN2L 3BA plain washer 4
PLN29 M5 plain washer 1 From S/No A678191 to A710068 See Issues 5 and 12
