Page 15 of 55
ILLUSTRATED PARTS MANUAL:
FLOWLINE COMB & WIRE
BINDER RANGE
PLN36 M8 plain washer 2
PLN37 M9 shim washer 1
RTS19 Tap/D/46/BS Pop Rivet (For C/Fan) 5 US Variant only – See Issue 16
RTS73 3.2 x 8mm fashtech euro rivet 3
SCM157 M6 x 20 pan torx taptite screw 8
SCM158 M5 x 16 pan torx taptite screw 2
SCM159 M6 x 50 pan torx taptite screw 3
SCM160 M4 x 12 pan torx taptite screw 7 Was 6 off – See Issue 14
SCM162 M4 x 10 pan head torx m/c screw 3
SCM163 M3 x 10mm pan torx taptite 2
SCR718 M4 x 10 Plasform 1 Pozi Pan screw 2 See Issue 6 – 230v only
SCR720 M3.5 x 10 pan torx plastech screw 9
SCR721 M2.5 x 8 Rec Pan plastech screw 2
SCR722 M5 x 16 pan plasfix screw 8
SCR724 M3 x 8 plastech pan head torx 6
SCR725 M5 x 20 plastfix pan head torx 7
SHK2 3BA Shakeproof Washer 2
SL17-144 Cable Tie 6
SL17-300 Binder Motor PCB 1 To S/No A721021 – See Issue 14
SL17-301 Binder LED PCB 1 To S/No A721021 – See Issue 14
SL17-312 Binder Main PCB – 120v 1 US Variant only – See Issue 16
SL17-313 Binder LED PCB 1 From S/No A721022 – See Issue 14
SL17-314 Binder Motor PCB 1 From S/No A721022 – See Issue 14
SL18-361 Cable Clamp 1 See Issue 6 – 230v only
SL18-366 Spring Plunger 1
SL18-368 PCB Mounting block PCB 3
SL18-380 Insulating Tape (RS494-679) in mm 75 See Issue 7. Was SL18-377 x 100mm See issue 8
SL18-381 Strain Relief Bushing 1 US Variant only – See Issue 16
SL18-383 Printed Button 1 From S/No A721022 – See Issue 14
SL20-317 Motor 1
SL20-322 Motor – 120v 1 US Variant only – See Issue 16
SL25-11 Cooling Fan 1 US Variant only – See Issue 16
SL4-124 Cord Set UK – 2 core 1
SL4-125 Cord Set EURO – 2 core 1
SL4-128 Cord Set US – 2 core 1 US Variant only – See Issue 16
SL4-129 Cord Set AUST – 2 core 1 See Issue 13
SL6-59 25MFD Capacitor 1 US Variant only – See Issue 16
SL6-76 9MFD Capacitor 1
SL8-173 Foot Switch 1
TRU100 E Clip 2
TRU99 Carbon Steel E Clip 3
A55173B Infill Panel Assembly CB405E 1 Comprises D55112A, D55117, D55118, D55119, D55133A,
D55149 and D55159
A55173I Infill Panel Assembly CB405E US 1 Comprises D55112C, D55117, D55118, D55119, D55133G,
D55149 and D55159
A55174B Comb Opening Mechanism (Spares)
Not supplied as an assembly
1 Comprises D55076, D55077, D55078, D55079, D55091,
D55132, D55135, D55136, D55213, SL17-301 and A55173B
A55059A Die Block Assembly (Spares) 1 Comprises D55050, D55051, D55053, D55056, D55065,
D55087, D55156, PEG93, PEG95 and SCM159
A55064 Edge Margin Guide Assembly (Spares) 1 Comprises D55108 and D55109
A55180B Push Plate Assembly (Spares) 1 Comprises D55228, D55155 and RTS73
A55222 Motor/Gearbox Assembly (Spares) 1 Comprises BSH78, BSH79, D55072, D55073, D55074,
D55162, D55163, D55189, D55191, D55193, D55215,
D55219, D55220, D55226, D55236, D55240, SCM160
(2off), SCM162, SCR722 (4off), SCR725, SHK2, SL6-72,
To Next Page
