ILLUSTRATED PARTS MANUAL:
FLOWLINE COMB & WIRE
BINDER RANGE
MODEL WB705E
Part No Description Qty Comments
A55207 Mobile Jaw Assembly 1
A55216 Quadrant Gear RH 1
A55217 Quadrant Gear LH 1
A55259 Spring Release Assembly LH 1 From S/No A740634 – See Issue 17
A55260 Spring Release Assembly RH 1 From S/No A740634 – See Issue 17
BSH78 Oilite Bearing 1
BSH79 Oilite Bearing AL1824 1
D000430 Wire Adjuster Indicator Decal 1 To S/No A692162 – See Issue 9
D000431 Footswitch Decal 1 Fitted to Footswitch by Supplier
D55053 Spacer Block 1
D55062A Side Frame LH 1 Made from D55062. To S/No A740633 – See Issue 17
D55062C Side Frame LH 1 Made from D55062B. From S/No A740634 – See Issue 17
D55066 Punch Selector 2
D55072 Gear Shaft Long 1
D55073 Gearbox Top Casing 1
D55074 Gearbox Bottom Casing 1
D55080 Wire Closing Link RH 1 To S/No A740633 – See Issue 17
D55081 Punch Handle Side Piece LH 1
D55083B Wire Closing Jaw Fixed 1 To S/No A692161 – See Issue 10
D55083P Wire Closing Jaw Fixed 1 From S/No A692162 – See Issue 10
D55084 Punch Handle Side Piece RH 1
D55085 Handle Grip Long 1
D55089 Wire Closing Adjuster Shaft 1
D55090 Wire Adjuster Cam 2
D55092 Wire Closing Link LH 1 To S/No A740633 – See Issue 17
D55094 Die Plate Wire Binder 1
D55095 Stripper Plate 2
D55098 Punch 34
D55100 Spacer Washer 6
D55101 Handle Lock Cam LH 1
D55102 Handle Lock Cam RH 1
D55108 Margin Adjuster Screw 1
D55109 Margin Adjuster Thumb Wheel 1
D55110F Top Cover 1
D55111A Bottom Casing 1
D55112B Document Measurer 1 Supplied as part of A55176A – See Issue 19
D55115A Side Frame RH 1 Made from D55115. To S/No A740633 – See Issue 17
D55115C Side Frame RH 1 Made from D55115B. From S/No A740634 – See Issue 17
D55116 Wire Thumb Wheel Support Block 1
D55121 Wire Adjuster Thumb Wheel 1
D55122 Wire Adjuster Wheel Gear 1
D55123 Rubber Foot Back/Top 2
D55124 Wire Closing Spring 2 Replaced by D55244 – See Issue 10
D55125 Document Support/lid 1
D55128 Wire Closing Cover 1 To S/No A713322 – See Issue 15
D55128P Wire Closing Cover Printed 1 From S/No A713323 – See Issue 15
D55130 Clippings Tray 1
D55135 Punch Button 1
D55136 Punch Button Spring 1
D55138 Punch Selector Spring 2
D55140 Punch Selector Switch M 1
D55141 Punch Selector Switch L 1
