ILLUSTRATED PARTS MANUAL:
FLOWLINE COMB & WIRE
BINDER RANGE
D55142A Infill Panel 1 Supplied as part of A55176A – See Issue 19
D55146 Comb Opening Bung 2
D55148 PCB Activation Cam 1
D55150 Wire Adjuster Worm Gear 1
D55159 Document Measurer Spring 1 Supplied as part of A55176A – See Issue 19
D55162 Motor Pinion 1
D55163 Gear Shaft Short 1
D55170 Push Plate Wire Binder 1
D55171 Pull Plate 1
D55189 Compound gear 34/13T 1
D55190 Compound gear 41/10T (Plastic) 1 To S/No A678190 Replaced by D55241/PLN29 – See Issue 5
D55191 Spur Gear 29T 1
D55192 Spur Gear 13T 2
D55193 Motor Support Bracket 1
D55194 Hex Spindle for gearbox 1
D55195 Hexagon Spindle 1
D55198 Buffer 2
D55200 Fixed spindle 2
D55202 Rubber Foot - L Shape 2
D55203 Rubber foot – front 2
D55206 Die Support Block 1
D55208 Punch Retainer 1
D55210 Gear Cap 1 Replaced by D55243 – See issue 10
D55213 Punch Switch Insulation collar 1
D55215 Compound Gear 1
D55219 Motor insulator 1
D55220 Gearbox 1
D55225 Foot Pedal Socket and Lead 1
D55226 Wires - Cap to PCB 1
D55230 Handle Lock Spindle 1
D55236 Gear Box Shaft Retainer 1 See Issue 3
D55237 WB705E LED PCB Cover 1 See Issue 2
D55240 Compound Gear 41/10T (Sintered) 1 See Issue 12
D55241 Compound Gear 41/10T (Metal) 1 From S/No A678191 To A710068 See Issues 5 and 12
D55242 Thermal Fuse Assembly 1 From S/No A670764 to A694089 See Issues 4 and 11
D55243 Metal Gear Clamp 1 See Issue 10
D55244 Wire Closing Spring 1 See Issue 10
D55245 Jaw Spacer 1
D55249 PCB Switch Insulator 1 From S/No A740634 – See Issue 14
D55273 Ribbon Cable Support 1 From S/No A740634 – See Issue 17
NM17 M6 Nyloc Nut 2 From S/No A692162 – See Issue 10
PEG93 6 x 50mm heavy duty spirol pin 3
PEG96 2.6 x 10 medium duty spirol 34
PEG97 6mm dia x 16mm long dowel pin 2
PLN2L 3BA plain washer 2 Was 4 off – See Issue 10
PLN29 M5 plain washer 1 From S/No A678191 to A710068 See Issues 5 and 12
PLN36 M8 plain washer 2
RTS73 3.2 x 8mm Fastech Euro Rivet 6 Was 3 off – See Issue 20
SCM13 M6 x 40 hex head screw 2 From S/No A692162 – See Issue 10
SCM157 M6 x 20 pan torx taptite screw 6 Was 8 off – See Issue 10
SCM158 M5 x 16 pan torx taptite screw 2
SCM159 M6 x 50 pan torx taptite screw 3
SCM160 M4 x 12 pan torx taptite screw 5 Was 6 off – See Issue 10, Was 4 off – See Issue 14
SCM162 M4 x 10 pan head torx m/c screw 3
SCR718 M4 x 10 Plasfom 1 Pozi Pan screw 2 See Issue 6
SCR720 M3.5 x 10 pan torx plastech screw 9
