ILLUSTRATED PARTS MANUAL:
FLOWLINE COMB & WIRE
BINDER RANGE
SCR721 M2.5 x 8 Rec Pan plastech screw 2
SCR722 M5 x 16 pan plasfix screw 8 Was 10 off – See Issue 10
SCR723 M6 x20 Rec Pan plastech screw 1
SCR724 M3 x 8 plastec pan head torx 6
SCR725 M5 x 20 plastfix pan head torx 7
SHK2 3BA Shakeproof Washer 2
SL17-144 Cable Tie 6
SL17-300 Binder Motor PCB 1
SL17-301 Binder LED PCB 1
SL17-313 Binder LED PCB 1 From S/No A(TBA) – See Issue 14
SL17-314 Binder Motor PCB 1 From S/No A(TBA) – See Issue 14
SL18-361 Cable Clamp 1 See Issue 6
SL18-368 PCB Mounting Block 3
SL18-380 Insulating Tape (RS494-679) in mm 75 See Issue 7. Was SL18-377 x 100mm See Issue 8
SL18-383 Printed Button 1 From S/No A(TBA) – See Issue 14
SL20-317 Motor 1
SL4-124 Cord Set UK – 2 core 1
SL4-125 Cord Set EURO – 2 core 1
SL4-129 Cord Set AUST – 2 core 1 See Issue 13
SL6-76 9MFD Capacitor 1
SL8-173 Foot Switch 1
TRU100 E Clip 2
TRU99 Carbon Steel E Clip 3
A55064 Edge Margin Guide Assembly (Spares) 1 Comprises D55108 and D55109
A55176A Infill Panel Assembly WB705E 1 Comprises D55142A, D55112B and D55159
A55178 Wire Closing Adjuster Kit 1 Comprises D55083P, D55089, D55090, D55116, D55121,
D55122, D55150, D55237, D55243, D55244, D55245,
NM17, SCM13, SCR723 and TRU99 – See Issue 10
A55183 Push Plate Assembly (Spares) 1 Comprises D55170, D55171 and RTS73
A55182 Die Block Assembly (Spares) 1 Comprises D55053, D55094, D55095, D55098, D55100,
D55206, D55208, PEG93, PEG96 and SCM159
A55222 Motor/Gearbox Assembly (Spares) 1 Comprises BSH78, BSH79, D55072, D55073, D55074,
D55162, D55163, D55189, D55191, D55193, D55215,
D55219, D55220, D55226, D55236, D55240, SCM160
(2off), SCM162, SCR722 (4off), SCR725, SHK2, SL6-72,
SL17-144, SL20-317 and TRU99 See Issue 12
A55223 Punch Handle Side Piece Assembly RH
(Spares)
1 Comprises D55084 and PEG97
A55224 Punch Handle Side Piece Assembly LH
(Spares)
1 Comprises D55081 and PEG97
A55238 Side Frame Assembly LH (Spares) 1 Comprises D55062A and D55200 (1off)
A55239 Side Frame Assembly RH (Spares) 1 Comprises D55115A and D55200 (1off)
