13
1. Check the fuel and water levels.
2. Connect the power cord to the power socket and press the Reset switch on the plug to
connect power to the heater.
3. Press the “Power” button. Once the heater has been activated, the “Burn” indicator (3) is lit.
4. Use the temperature control buttons (6) to set the desired temperature.
5. The oil burner is deactivated once the desired temperature is reached. It is restarted once the
water temperature drops 2 or 4 degrees below the set target temperature.
6. Deactivate the water heater by pressing the “Power” button again.
WARNING! The heater must always be protected against water spatter. Please take this into
account during installation and use!
NOTE! The heater’s operating voltage is 230 V/50 Hz. It is the responsibility of the user to
connect the device to a power grid that supplies the appropriate voltage.
NOTE! Do not turn off the heater by pulling the power plug out of the socket.
NOTE! Always deactivate the heater before refuelling it.
NOTE! If the Rexener water heater is used in winter, it must always be connected to power.
RECOMMENDATION : Use only high-grade biodiesel or light fuel oil in the heater. Always
ensure the cleanliness of the containers used for refuelling the heater. Container impurities
and the use of fuels other than light fuel oil or diesel may cause malfunctions or excessive soot
formation.
RECOMMENDATION : When handling fuel, observe all relevant safety instructions.
OPERATING INSTRUCTIONS
Recommended circulation pump properties
If a circulation pump has been acquired for the Rexener water heater, it is always on when the
heater burner is active. When the heater is switched off, the circulation pump shuts down. The
water heater requires a circulation pump to function.
Operating voltage
230V~, 50Hz
Flow speed
6100 L/h 6 m.c.H
2
O
Highest flow rate
9.6 m.c.H
2
O
Lowest flow rate
2 m.c.H
2
O
Using the rexener water heater
Circulation pump
