PRODUCT SPECIFICATION
Product name REXENER Water Boiler
Model name PR-200
Heating output 18.5 kW
96 %
Fuel consumption 1.94L/h
Fuel Diesel
Burner type Gun type oil
Usage Pool Heating Boiler
Water tank capacity 17.1 Liter
Maximum operating
pressure
1.7 bar
(167kPa)
Power 230V~, 50Hz
Rated Power Consumption 80W
IP Grade IP 33
Dimension
(W x D x H)
320x580x839 mm
Weight 38kg
Pipe size of water out Inner diameter (45mm), Outer diameter (52mm), 40A
Pipe size of water in Inner diameter (45mm), Outer diameter (52mm), 40A
Exhaust pipe diameter(Ø) Ø 75mm
Safety device
Flame detecting, Low water level detecting, Water
temperature, Over heating protection
※ Heating efficiency rated is measured at supply temperature
of 40℃ and return temperature of 25℃.
