10.2.3 Housing dimensions of the fan
Fig. 10-8: Fan, front view (in mm)
10.3 Mounting the control
10.3.1 General information
Destruction of the components due to the
mounting of the control, module, Inline termi-
nals or connectors under voltage!
● Before mounting or demounting components, disconnect the control - includ-
ing its components - from the voltage
● Connect the voltage only after the control and its components have been set
up
L25, L45, L65, L75 and L85
Bosch Rexroth AG
Mounting, demounting and electric installation
DOK-CONTRL-IC*LX5*****-IT02-EN-P
21/53
