Radial piston motor for compact drives | MCR-C
Ordering code
5
Ordering code
01 02 03 04 05 06 07 08 09 10 11 12 13 14 15 16
MCR 20 C F280 Z / 33 42
Radial piston motor
01 Radial-piston type, low-speed, high-torque motor
MCR
Frame size
02 Frame size 20
20
Housing type
03 Short front case ‒ rear case mounting fl ange
C
Nominal size, displacement V
g
in cm
3
/rev
04 Frame size 20
1750 2100 2500 3000
Low displacement: motors use standard cylindrical pistons
LD ●●––
High displacement: motors use stepped pistons
HD ––●●
Drive shaft
05 With fl ange ø280 mm
F280
Rear shaft
06 Without rear shaft
Z
Series
07 Series 33
33
1)
Brake
08 Without brake
A0
Hydraulic release spring applied multi-disc holding brake 19000 Nm
B19
Seals
09
NBR (nitrile rubber)
M
FKM (fl uoroelastomer / Viton)
V
Single/two-speed operation
10 Single speed, standard direction of rotation
1L
Bi-directional two speed, standard direction of rotation
2WL
Ports
11 Tapped with UNF thread (SAE J514)
(A and B ports SAE split fl ange metric bolt holes)
42
Studs
12 Without studs (no code)
With wheel studs and nuts
S
With twice normal number of wheel studs and nuts
SS
Speed sensor
13 Without sensor (no code)
Sensor ready
P0
Sensor without regulator
P1
Sensor with regulator
P2
●
= Available – = Not available
1) This data sheet also applies to series 32. Other options available
on request.
