Radial piston motor for compact drives | MCR-C
Technical data
7
Technical data
Frame size MCR20
Type of mounting Flange mounting
Pipe connections
1)2)
Threaded per SAE J514; Flanged per SAE J518
Shaft loading see page 9
Weight
Single speed (1L) m kg 121
Two speed (2WL) m kg 121
Hydraulic fl uid
3)
Mineral oil type HLP/HLVP to DIN 51524
Fluid cleaniness
ISO 4406, Class 20/18/15
Fluid viscosity range
ν
min/max
mm²/s
10 to 2000
Fluid temperature range
4)
θ
min/max
°C
-20 to +85
Pressure Low displacement High displacement
Maximum diff erential pressure
5)6)
Δp
max
bar 450 400
Maximum pressure at port A or B
5)6)
p
max
bar 470 420
Maximum case drain pressure
p
case max
bar 10 10
Motor performance
Displacement
V
g
cm
3
/rev 1750 2100 2500 3000
Specifi c torque Nm/bar 28 33 40 44
Maximum torque
5)
T
max
Nm 12533 15040 15915 19099
Minimum speed for smooth running
7)
n
min
rpm 0.5 0.5 0.5 0.5
Maximum speed (1L and 2WL)
8)9)
n
max
rpm 125 125 115 115
MCR20
Holding brake (disc brake) B19
Minimum holding torque
t
min/max
Nm
19000
Release pressure (min)
p
rel min
bar
15
Release pressure (max)
p
rel max
bar
30
Maximum pressure at brake port „Z“
p
max
bar
30
Oil volume to operate brake
V
rel
cm
3
99
1) Ensure motor case is fi lled with oil prior to start-up.
2) For installation and maintenance details, please see instruction
manual 15215-B.
3) For any other fl uid type contact the Engineering Department at
Bosch Rexroth, Glenrothes. For more information on hydraulic fl u-
ids, see datasheets 90220 and 90223.
4) Extension of the allowable temperature range may be possible de-
pending on specifi cation. Please consult Bosch Rexroth Engineer-
ing Department in Glenrothes for further details.
5) Maximum values should only be applied for a small portion of the
duty cycle. Please consult Bosch Rexroth Engineering
Department in Glenrothes for motor life calculations based on par-
ticular operating cases.
6) When operating motors in series, please consult Bosch Rexroth
Engineering Department in Glenrothes.
7) For continuous operation at speeds <5 rpm please consult Bosch
Rexroth Engineering Department in Glenrothes.
8) Based on nominal no-load Δp of 20 bar in full-displacement mode.
9) Warning! During the running in period of the motor (min. 20 hrs) it
should not be run unloaded at >100 rpm.
Notice
▶ Motor performance values are based on theoretical
calculations.
▶Effi ciencies are not taken into consideration for theo-
retical calculations.
▶ Brake torque accounts for tolerances. Values are based
when used with standard mineral oil (HLP)
Please refer the related foot notes for more details.
