REXROTH VT 3006 - Technical Data; Operating Voltage and Range; Input Specifications; Output Stage Specifications

Hydraulics Bosch Rexroth AG
RE 29926/10.06 VT 3006
5/8
Technical Data (For application outside these parameters please consult us!)
Operating voltage
1)
U
B
24 VDC +60 % –5 %
Operating range:
– Upper limit value
u
B
(t)
max
39 V
– Lower limit value
u
B
(t)
min
22 V
Power consumption
P
S
< 50 VA
Current consumption
I
< 1 A (with loading current)
Fuse
I
S
2.5 A T
Inputs:
– Command value 1 to 4
U
e
±9 V (reference potential is M0)
– Command value 5
U
e
±6 V (reference potential is M0)
– Command value (differential input)
U
e
0 to ±10 V; R
e
= 100 kΩ
Ramp time (setting range)
t
30 ms to approx. 1 s or 5 s
Outputs:
– Output stage
• Solenoid current/resistance
I
max
800 mA; R
(20)
= 19.5 Ω
• Biasing current
I
V
20 mA ±25 %
• Pulse frequency f 170 Hz ±10 %
– Regulated voltage
U
±9 V ±1 %; ±25 mA externally loadable
– Measuring sockets
• Current command value „w“
U ±6 V; R
i
= 5 kΩ
• Current actual value „I
A
“; „I
B
“
U
A
; U
B
0 to 800 mV equivalent 0 to 800 mA
Relay data:
– Nominal voltage
I operating voltage U
B
– Threshold voltage
U
16.8 V
– Return voltage
U
2.4 V
– Coil resistance
R
2150 Ω
Type of connection 32-pin terminal strip, DIN 41612, form D
Card dimensions Euro-card 100 x 160 mm, DIN 41494
Front plate dimensions
– Height 3 HE (128,4 mm)
– Width soldering side 1 TE (5,08 mm)
– Width component side 7 TE
Permissible operating temperature range
J
0 to 50 °C
Storage temperature range
J
–25 to 85 °C
Weight
m
0.15 kg
1)
To guarantee the max. solenoid current for the solenoid
(19,5 Ω) in the complete solenoid temperature range the
operating voltage must be at least 28 VDC!
Note!
For details regarding environmental simulation test in the
field of EMC (electromagnetic compatibility), climate and me-
chanical stress, see RE 30304-U (declaration on environmen-
tal compatibility).
