Ruijie RG-NBS3100 Series Switches Hardware Installation and Reference Guide Product Overview
11
AC input
Rated voltage range: 100 V to 240 V
Maximum voltage range: 90 V to 264 V
Frequency: 50/60 Hz
Rated current: 2A
Power cord: 10A
Ports 1 to 8 support PoE/PoE+ with the maximum power output of 30 W per port. Port 9 does not
support PoE.
The overall maximum output power of PoE/PoE+ is 125 W.
Mode A (data pairs 1-2 and 3-6)
11W with no PoE load;
145W with PoE full load
Operating temperature: 0°C to 50°C (32°F to +122°F)
Storage temperature: -40°C to +70°C (-40°F to +158°F)
Operating humidity: 10% to 90% RH
Storage humidity: 5% to 95% RH
Accessing Optical
Module
Information
300 mm x 220 mm x 43.6 mm
Device operation in a residential environment may cause radio interference.
The high temperature label indicates that the devie must be installed in the restricted area when the
ambient temperature exceeds 50°C .
Product Appearance
