Ruijie RG-NBS3100 Series Switches Hardware Installation and Reference Guide Product Overview
4
LED
Panel Identification
State
Meaning
System status LED
Status
Off
The switch is not receiving power.
Blinking green
(0.5 Hz)
The switch is running, but is not connected to
Ruijie Cloud.
Blinking green (10
Hz)
The switch is being upgraded or initialized.
Solid green
The switch is connected to Ruijie Cloud.
10/100/1000Base-T
Ethernet port status
LED
1–24
Off
The port is not connected.
Solid green
The port is connected at a rate of 10/100/1000
Mbps.
Blinking green
The port is receiving or transmitting traffic.
SFP port status LED
25–28
Off
The port is not connected.
Solid green
The port is connected at a rate of 100/1000
Mbps.
Blinking green
The port is receiving or transmitting traffic.
1.2 RG-NBS3100-24GT4SFP-P
Technical Specifications
Model
RG-NBS3100-24GT4SFP-P
CPU
Built-in CPU, single-core processor, and 500 MHz
Flash Memory
16 MB
SDRAM
DDRIII 256 MB
Optical Module
The copper cable is not supported. See Appendix B.
The supported module type may change at any time. Consult Ruijie Networks for the latest
information.
SFP Port
1000Base-X
100Base-X
Power Supply
 AC input
Rated voltage range: 100 V to 240 V
Maximum voltage range: 90 V to 264 V
Frequency: 50/60 Hz
Rated current: 6 A
Input Leakage
Current
≤ 3.5 mA
EEE
Supported
PoE
PoE/PoE+ support
Ports 1 to 24 support PoE/PoE+ with the maximum power output of 30 W per port.
The overall maximum output power of PoE/PoE+ is 370 W.
PoE Mode
Mode A (data pairs 1-2 and 3-6)
Power
Consumption
21 W with no PoE load
443 W with PoE full load
