RF Mogul Eagle Operation Manual

The Eagle Manual
12
SWM Block Diagram
Block DiagramBlock Diagram
Block Diagram
IDU Receiver line
Note:
The SWM LNB has 8
channels available. Each DVR
takes 2 channels (one coax). A
non DVR uses one channel (one
coax). You may use any
combination of receivers until
you use up all 8 channels.
Example: A HR34 uses 5
channels leaving 3 channels
available.
DIRECTV
SWM
INSTALLATION
4 Port splitter shown.
8 Port splitter is available
INSET
110 Volts AC
Note: See bottom of IDU
for wiring instructions.

RF Mogul Eagle Specifications

General

Brand	RF Mogul
Model	Eagle
Category	Satellite TV System
Language	English
