Performance Data
13AJN Series
6
Performance Data @ AHRI Standard Conditions—Cooling
Model Numbers
80°F [26.5°C] DB/67°F [19.5°C] WB Indoor Air
95°F [35°C] DB Outdoor Air
Sound
Rating
dB
Indoor
CFM [L/s]
Outdoor
Unit
13AJN
Indoor
Coil and/or
Air Handler
Total
Capacity
BTU/H [kW]
Net
Sensible
BTU/H [kW]
Net
Latent
BTU/H [kW]
EER SEER
18
(AJN)
RCQD-2417(RGJF-06?MCK?) 18,800 [5.5] 15,300 [4.5] 3,500 [1.0] 12.00 14.50 72 625 [295]
RCQD-2417(RGJF-07?MCK?) 18,800 [5.5] 15,300 [4.5] 3,500 [1.0] 12.00 14.50 72 575 [271]
RCQD-2417(RGPE-05?BMK?) 18,700 [5.5] 15,200 [4.5] 3,500 [1.0] 12.00 14.50 72 575 [271]
RCQD-2417(RGPE-07?AMK?) 18,800 [5.5] 15,300 [4.5] 3,500 [1.0] 12.00 14.50 72 625 [295]
RCQD-2417(RGPT-05?BMK?) 19,000 [5.6] 15,600 [4.6] 3,400 [1.0] 12.00 14.50 72 650 [307]
RCQD-2417(RGPT-07?AMK?) 18,700 [5.5] 15,200 [4.5] 3,500 [1.0] 12.00 14.50 72 625 [295]
RCQD-2417(RGRM-04?MAE?) 18,700 [5.5] 15,200 [4.5] 3,500 [1.0] 12.00 14.50 72 575 [271]
RCQD-2417(RGRM-06?MAE?) 18,700 [5.5] 15,200 [4.5] 3,500 [1.0] 12.00 14.50 72 600 [283]
RCQD-2417(RGRM-07?MAE?) 18,600 [5.4] 15,100 [4.4] 3,500 [1.0] 12.00 14.50 72 625 [295]
RCQD-2417(RGTM-06?MAE?) 18,700 [5.5] 15,200 [4.5] 3,500 [1.0] 12.00 14.50 72 625 [295]
RCQD-2417(ROCA-070E03) 18,800 [5.5] 15,300 [4.5] 3,500 [1.0] 12.00 14.50 72 600 [283]
RCQD-2417(ROLA-070E03) 18,700 [5.5] 15,200 [4.5] 3,500 [1.0] 12.00 14.50 72 600 [283]
RCQD-2417+RXMD-C04 18,200 [5.3] 14,800 [4.3] 3,400 [1.0] 11.50 13.50 72 650 [307]
RHKL-HM2417(RCSL-H*2417) 18,400 [5.4] 13,900 [4.1] 4,500 [1.3] 12.00 14.50 72 650 [307]
RHLL-HM2417(RCSL-H*2417) 17,900 [5.2] 13,300 [3.9] 4,600 [1.3] 12.00 14.50 72 600 [283]
RHSL-HM1817(RCSL-H*2417) 17,700 [5.2] 13,100 [3.8] 4,600 [1.3] 11.00 13.00 72 600 [283]
24
(AJN)
RCFL-H*2417
➀
23,000 [6.7] 17,100 [5.0] 5,900 [1.7] 10.50 13.00 73 800 [378]
RHAL-FR24P 23,400 [6.9] 18,500 [5.4] 4,900 [1.4] 11.00 13.00 73 800 [378]
RHBL-FR24T 23,400 [6.9] 18,500 [5.4] 4,900 [1.4] 11.50 14.00 73 800 [378]
RCFL-A*2414 23,000 [6.7] 17,100 [5.0] 5,900 [1.7] 10.50 13.00 73 800 [378]
RCFL-A*2417 23,000 [6.7] 17,100 [5.0] 5,900 [1.7] 10.50 13.00 73 800 [378]
RCFL-A*2417(RGFE-06?MCK?) 23,400 [6.9] 17,350 [5.1] 6,050 [1.8] 11.50 14.00 73 800 [378]
RCFL-A*2417(RGFE-07?MCK?) 23,200 [6.8] 16,950 [5.0] 6,250 [1.8] 11.50 14.00 73 725 [342]
RCFL-A*2417(RGFG-06?MCK?) 23,200 [6.8] 16,900 [5.0] 6,300 [1.8] 11.50 14.00 73 725 [342]
RCFL-A*2417(RGFG-07?MCK?) 23,600 [6.9] 17,500 [5.1] 6,100 [1.8] 11.50 13.50 73 800 [378]
RCFL-A*2417(RGGE-06?MCK?) 23,600 [6.9] 17,550 [5.1] 6,050 [1.8] 11.50 14.00 73 825 [389]
RCFL-A*2417(RGGE-07?MCK?) 23,600 [6.9] 17,550 [5.1] 6,050 [1.8] 11.50 14.00 73 800 [378]
RCFL-A*2417(RGLT-07?AMK?) 23,000 [6.7] 16,600 [4.9] 6,400 [1.9] 11.50 14.00 73 675 [319]
RCFL-A*2417(RGPE-07?AMK?) 23,600 [6.9] 17,550 [5.1] 6,050 [1.8] 11.50 14.00 73 825 [389]
RCFL-A*2417(RGPT-05?BMK?) 23,800 [7.0] 17,900 [5.2] 5,900 [1.7] 11.50 13.50 73 850 [401]
RCFL-A*2417(RGPT-07?AMK?) 23,800 [7.0] 17,900 [5.2] 5,900 [1.7] 11.50 14.00 73 850 [401]
RCFL-A*2417(RGRM-04?MAE?) 23,400 [6.9] 17,400 [5.1] 6,000 [1.8] 11.50 13.50 73 800 [378]
RCFL-A*2417(RGRM-06?MAE?) 23,400 [6.9] 17,400 [5.1] 6,000 [1.8] 11.50 13.50 73 825 [389]
RCFL-A*2417(RGRM-07?MAE?) 23,600 [6.9] 17,750 [5.2] 5,850 [1.7] 11.50 13.00 73 850 [401]
RCFL-A*2417(RGTM-06?MAE?) 23,400 [6.9] 17,200 [5.0] 6,200 [1.8] 11.50 14.00 73 750 [354]
RCFL-A*2417(RHWB-04WMX36A) 23,600 [6.9] 17,700 [5.2] 5,900 [1.7] 11.50 14.00 73 825 [389]
RCFL-A*2417(ROCA-070E03) 23,600 [6.9] 17,550 [5.1] 6,050 [1.8] 11.50 14.00 73 800 [378]
RCFL-A*2417(ROCA-070E04) 23,600 [6.9] 17,550 [5.1] 6,050 [1.8] 11.50 14.00 73 800 [378]
RCFL-A*2417(ROLA-070E03) 23,600 [6.9] 17,550 [5.1] 6,050 [1.8] 11.50 14.00 73 800 [378]
RCFL-A*2417(ROLA-070E04) 23,200 [6.8] 16,950 [5.0] 6,250 [1.8] 11.50 14.00 73 725 [342]
RCFL-H*2414 23,000 [6.7] 17,100 [5.0] 5,900 [1.7] 10.50 13.00 73 800 [378]
RCFL-H*2417(RGFE-06?MCK?) 23,400 [6.9] 17,350 [5.1] 6,050 [1.8] 11.50 14.00 73 800 [378]
RCFL-H*2417(RGFE-07?MCK?) 23,200 [6.8] 16,950 [5.0] 6,250 [1.8] 11.50 14.00 73 725 [342]
RCFL-H*2417(RGFG-06?MCK?) 23,200 [6.8] 16,900 [5.0] 6,300 [1.8] 11.50 14.00 73 725 [342]
RCFL-H*2417(RGFG-07?MCK?) 23,600 [6.9] 17,500 [5.1] 6,100 [1.8] 11.50 13.50 73 800 [378]
RCFL-H*2417(RGGE-06?MCK?) 23,600 [6.9] 17,550 [5.1] 6,050 [1.8] 11.50 14.00 73 825 [389]
RCFL-H*2417(RGGE-07?MCK?) 23,600 [6.9] 17,550 [5.1] 6,050 [1.8] 11.50 14.00 73 800 [378]
RCFL-H*2417(RGJF-06?MCK?) 23,600 [6.9] 17,550 [5.1] 6,050 [1.8] 11.50 14.00 73 825 [389]
RCFL-H*2417(RGJF-07?MCK?) 23,600 [6.9] 17,550 [5.1] 6,050 [1.8] 11.50 14.00 73 800 [378]
RCFL-H*2417(RGLT-07?AMK?) 23,000 [6.7] 16,600 [4.9] 6,400 [1.9] 11.50 14.00 73 675 [319]
Rev.
5/17/12
➀ Highest sales volume tested combination required by D.O.E. test procedures. [ ] Designates Metric Conversions
