Rheem 14AJM SERIES User Manual

Air
Model I.D./Accessories/Compressor
14AJM Series
3
Model Number Identification
14 A J M 18
NOMINAL COOLING CAPACITY
18 = 18,000 BTU/HR [5.28 kW]
24 = 24,000 BTU/HR [7.03 kW]
30 = 30,000 BTU/HR [8.79 kW]
36 = 36,000 BTU/HR [10.55 kW]
42 = 42,000 BTU/HR [12.31 kW]
48 = 48,000 BTU/HR [14.07 kW]
49 = 47,000 BTU/HR [13.77 kW]
56 = 54,000 BTU/HR [15.83 kW]
60 = 60,000 BTU/HR [17.58 kW]
A 01
14.5 SEER A = AIR CONDITIONER VOLTAGE
J = 208-230
SINGLE PHASE
DESIGN
SERIES
M = 1ST DESIGN
R-410A
CABINET
A = FULL METAL JACKET
RHEEM
VALUE
SERIES
Accessories
• Low Pressure Control (RXAC-A07)
• High Pressure Control (RXAB-A07)
• Low Ambient Control (RXAD-A08)
• Compressor Time Delay Control
• Crankcase Heater
• Sound Enclosure
* Photos are representative. Actual models may vary.
For detailed thermostat match-up information,
see specification sheet form number T11-001.
300-Series *
Deluxe
Programmable
400-Series *
Special Applications/
Programmable
500-Series *
Communicating/
Programmable
200-Series *
Programmable
Scroll
®
Compressor
The reliable scroll compressor is the key to efficiency for this
Rheem model. It’s the latest in high-efficiency compressor tech-
nology. The advanced scroll compressor offers low noise and
vibration characteristics and features tolerance to liquid refrigerant
and system contamination. The scroll compressor also has low
start torque, reducing start problems in the field. And its unique
design enables air conditioners to perform efficiently and quietly.
[ ] Designates Metric Conversions
Thermostats
