Rheem 96MDV Series User Manual

Field Conversions
30
ST-A1194-32-01
Notes:
__ VERIFY ALL HOSES ARE SECURE AND FULLY SEATED.
__ CONFIRM THAT ALL HOSES ARE FREE OF KINKS.
__ CONFIRM ALL HOSES AND OTHER DRAIN PARTS HAVE A
SLOPE IN DIRECTION OF WATER FLOW.
__ BOTH WORM DRIVES ON THE HOSE CLAMPS OF THE FLUE TRANSITION
MUST BE LOCATED ON THE TOP OF THE COUPLING. SEE LOCATION
DETAIL IN THE GENERAL CONVERSION INSTRUCTIONS AT THE
BEGINNING OF THIS SECTION.
__ ALL CLAMPS AND COUPLINGS ARE TIGHTENED
__ ALL DRAIN PORTS ARE PLUGGED.
__ UNIT HAS FORWARD PITCH.
__ HEAT TAPE INSTALLED(IF REQUIRED)
Checklist:

Rheem 96MDV Series Specifications

General

Model Series	96MDV Series
Type	Gas Furnace
Fuel Type	Natural Gas or Propane
Efficiency	Up to 96% AFUE
Heat Exchanger	Stainless Steel
Cabinet Type	Multi-Position
Heating Capacity	40, 000 to 120, 000 BTU/hr
Blower Type	Variable Speed
Vent Type	Direct Vent
Warranty	Limited Lifetime Heat Exchanger
Stages	Two-stage heating
