Replacement Parts.
Key No. Description
1 Dip Tube
2 Grommet, Large
Grommet, Small
3 Seal Ring, Large
Seal Ring, Small
4 Vacuum Valve Assembly
5 Temperature and Pressure Relief Valve
6 Knock-Out Bracket
7 Screw, #8 x 3/4"
8 Junction Box Cover
9 Screw #8-16 x 5/8"
10 Upper Thermostat
11 Upper Protector
12 Screw, #10-16 x 5/8"
13 Thermostat Cavity Insulation
14 Upper Access Panel
15 Screw, #10-16 x 5/8"
16 Access Panel Cover Insulation
17 Access Panel Cover
18 Element Gasket
19 Upper Heating Element (Includes Key No. 18)
20 Lower Thermostat
21 Lower Protector
22 Lower Access Panel
23 Lower Heating Element (Includes Key No. 18)
24 Drain Valve
25 Reducer Bushing, 3/4" NPT x 1" NPT
26 5/16-18 Cap Screw
27 Lock Washer
▲
Element Wrench
▲
Pipe Wrap Energy Kit
▲
Use and Care Manual
▲
