6 Rheem Manufacturing Company
Model
Number
RARL-
ELECTRICAL
036JAZ 1-60-208/230 16.7/16.7 82 1.0 22/22
PHYSICAL
30/30 35/35 23.0 [2.14] 1 3900 [1841] 157 [4445]
Phase
Frequency (Hz)
Voltage (Volts)
Compressor
236 [107]
Fan Motor
Full Load
Amperes
(FLA)
Min.
Circuit
Ampacity
Amperes
Fuse or HACR
Circuit Breaker
246 [111.6]
Outdoor Coil
R-410a
Oz. [g]
Weight
Rated Load
Amperes
(RLA)
Locked Rotor
Amperes
(LRA)
Min.
Amperes
Max.
Amperes
Face Area
Sq. Ft. [m
2
]
No.
Rows
CFM
[L/s]
Net
Lbs. [kg]
Shipping
Lbs. [kg]
024JAZ 1-60-208/230 10.3/10.3 52 0.8 14/14 20/20 20/20 15.8 [1.47] 1 2285 [1078] 117 [3311] 190 [86.2] 200 [90.7]
048JAZ 1-60-208/230 21.2/21.2 96 1.0 28/28 35/35 45/45 23.0 [2.14] 1 3900 [1841] 154 [4354] 236 [107] 246 [111.6]
060JAZ 1-60-208/230 25.6/25.6 118 2.8 35/35 45/45 60/60 23.0 [2.14] 2
HS*3500 [1652]
LS*2800 [1322]
224 [6350] 305 [138] 315 [142.9]
AIR INLETS
(LOUVERS)
ALLOW 6 [152 mm]
MIN. CLEARANCE
3 SIDES
AIR DISCHARGE
ALLOW 60 [1524 mm] CLEARANCE
ALLOW 24 [610 mm]
ACCESS CLEARANCE
ACCESS
PANEL
L
W
H
ALTERNATE HIGH VOLTAGE
CONNECTION (KNOCKOUT)
1
11
/32 [34 mm]
Electrical and Physical Data
[ ] Designates Metric Conversions
SERVICE
FITTINGS
LOW VOLTAGE
CONNECTION
7
/80 [22 mm]
HIGH VOLTAGE
CONNECTION
1
11
/320 [34 mm]
LIQUID LINE
CONNECTION
SERVICE ACCESS
TO ELECTRICAL &
VALVES ALLOW
240 [610 mm]
CLEARANCE
ONE SIDE
2
7
/80 [73 mm] DIA.
ACCESSORY
KNOCKOUTS
VAPOR LINE
CONNECTION
HIGH PRESSURE
CONTROL
MANUAL RESET
(FIELD INSTALLED
ACCESSORY)
A
-
0
0
0
0
3
GENERAL TERMS OF LIMITED WARRANTY
Rheem will furnish a replacement for any part of this product
which fails in normal use and service within the applicable
period stated, in accordance with the terms of the limited
warranty.
For Complete Details of the Limited Warranty, Including Applicable Terms
and Conditions, See Your Local Installer or Contact the Manufacturer for
a Copy.
Rheem Prestige Series equipment features a 10-year limited
parts warranty.*
*This ten-year limited parts warranty is applicable only to single-phase
products installed in residential applications.
BEFORE PURCHASING THIS APPLIANCE, READ IMPORTANT ENERGY COST AND EFFICIENCY INFORMATION AVAILABLE
FROM YOUR RETAILER.
Model Number
RARL-
Height “H”
(Inches) [mm]
Length “L”
(Inches) [mm]
Width “W”
(Inches) [mm]
024 23 [584] 44
3
/8 [1127] 31
1
/2 [800]
036/048/060 33 [838] 44
3
/8 [1127] 31
1
/2 [800]
*HS = high speed
*LS = low speed
Unit Dimensions
