Diagnostics
DIAGNOSTICS
Service Analyzer Charts
SYMPTOM POSSIBLE CAUSE REMEDY
Moisture Poor evacuation on installation or during service In each case, the cure is the same� Recover refrigerant�
Add lter drier, evacuate, and recharge.
High head pressure Noncondensibles air
Unusual head and
suction readings
Wrong refrigerant or mixed refrigerants
Foreign matter –
copper lings
Copper tubing cuttings
Copper oxide Dirty copper piping or nitrogen not used when
brazing
Welding scale Nitrogen not used during brazing
Soldering ux Adding ux before seating copper partway
Excess soft solder Wrong solder material
LOSS OF LUBRICATION
SYMPTOM POSSIBLE CAUSE REMEDY
Compressor failures Line tubing too large Reduce pipe size to improve oil return�
Low suction pressure Low charge Check system charge�
Refrigerant leaks Repair and recharge�
Cold, noisy
compressor –
Slugging
Dilution of oil with refrigerant Observe piping guidelines�
Noisy compressor Migration Check crankcase heater�
Cold, sweating
compressor
Flooding Check system charge�
Low load Reduced airow Dirty lter
Dirty coil
Wrong duct size
Restricted duct
Thermostat setting
Advise customer�
Short cycling of
compressor
Faulty high- or low-pressure control Replace control�
Loose wiring Check all control wires�
Thermostat In supply air stream, out of calibration
Customer misuse
SLUGGING
SYMPTOM POSSIBLE CAUSE REMEDY
On start-up Incorrect piping Review pipe size guidelines�
TEV hunting when
running
Faulty TEV Replace TEV�
CONTAMINATION
