HYDRONIC AIR HANDLER ELECTRICAL PHYSICAL SPECIFICATIONS - ECO-TECH™ MODELS
Model Numbers
Nominal Heating Capacity BTU/hr [kw] 40000 [11.7] 60000 [17.6] 80000 [23.4] 100000 [29.3]
Air Side Temperature Rise* °F [°C] 32-53 [17.6-29.2] 24-43 [13.2-23.7] 25-49 [13.8-27.0] 25-46 [13.8-25.3]
Rated Heating CFM [L/s] 800 [378] 1200 [566] 1625 [767] 1800 [850]
Cooling Range CFM [L/s] 600-800 [283-556] 800-1200 [283-612] 1000-1625 [472-775] 1200-1800 [612-804]
Power Supply (V - HZ - PH) 115 - 60 - 1
Minimum Circuit Ampacity - Amps 8 10 12.9 12.9
Max Rating of Over Current Protective Device - Amps 11.7 18 23.2 23.2
Maximum Fuse or Circuit Breaker Size - Amps 10 15 20 20
Motor HP [W] 1/3 [248] 1/2 [373] 3/4 [559] 3/4 [559]
Blower (D x W) in [mm] 10 x 6 [254 x 152] 10 x 8 [254 x 203] 10 x 10 [254 x 254] 11 x 11 [279 x 279]
Blower Motor Type EcoTech / ECM Type
Pump Type Wet Rotor
Pump Power Supply (V - HZ - PH) 115 - 60 - 1
Pump Motor RLA/LRA - Amps 1.8
Pump HP [W] 1/8 [.86]
Pump Maximum Working Pressure psi [kPa] 125 [861]
Max Working Temperature °F [°C] 160 [71]
Water Connection Type Copper Studs
Inlet Water Connection Diameter in [mm] 3/4 [19]
Out Water Connection Diameter in [mm] 3/4 [19]
Shipping Weight LBS [kg] 91 [41] 100 [45] 122 [55] 129 [58]
RW1T04A2414NAA RW1T06A3617NAA RW1T08A4821NAA RW1T10A6024NAA
Model Numbers
Nominal Heating Capacity BTU/hr [kw] 40000 [11.7] 60000 [17.6] 80000 [23.4] 100000 [29.3]
Air Side Temperature Rise* °F [°C] 32-53 [17.6-29.2] 24-43 [13.2-23.7] 25-49 [13.8-27.0] 25-46 [13.8-25.3]
Rated Heating CFM [L/s] 800 [378] 1200 [566] 1625 [767] 1800 [850]
Cooling Range CFM [L/s] 600-800 [283-556] 800-1200 [283-612] 900-1625 [424-641] 1050-1850 [472-873]
Power Supply (V - HZ - PH) 115 - 60 - 1
Minimum Circuit Ampacity - Amps 5 10 11 11
Max Rating of Over Current Protective Device - Amps 7.0 15.3 17.6 18.2
Maximum Fuse or Circuit Breaker Size - Amps 15 15 15 15
Motor HP [W] 1/5 [93] 1/2 [373] 3/4 [559] 3/4 [559]
Blower (D x W) in [mm] 10 x 6 [254 x 152] 10 x 8 [254 x 203] 10 x 10 [254 x 254] 11 x 11 [279 x 279]
Blower Motor Type PSC
Pump Type Wet Rotor
Pump Power Supply (V - HZ - PH) 115 - 60 - 1
Pump Motor RLA/LRA - Amps 1.8
Pump HP [W] 1/8 [.86]
Pump Maximum Working Pressure psi [kPa] 125 [861]
Max Working Temperature °F [°C] 160 [71]
Water Connection Type Copper Studs
Inlet Water Connection Diameter in [mm] 3/4 [19]
Out Water Connection Diameter in [mm] 3/4 [19]
Shipping Weight LBS [kg] 91 [41] 100 [45] 122 [55] 129 [58]
RW1P04A2414NAA RW1P06A3617NAA RW1P08A4821NAA RW1P10A6024NAA
