5
GENERAL INFORMATION
FIGURE 2
THE RWMV SERIES HYDRONIC AIR HANDLERS ARE DESIGN-CERTIFIED BY UL
1. DOOR SWITCH
2. JUNCTION BOX
3. TRANSFORMERS
4. TERMINAL BLOCK
5. CONTROL BOARD
6. BLOWER
7. PUMP (IF REQUIRED)
8. WATER INLET (OUTLET FOR 14” HAH)
9. WATER OUTLET (INLET FOR 14” HAH)
10. BLOWER MOTOR
11. HYDRONIC COIL ASSEMBLY
12. PUMP CONTROL
13. CHOKE (3/4HP ONLY)
ST - A1260 - 01 - 00
11
8
9
10
6
4
7
5
1
2
3
13
12
