Capabilities & Specifications
Important Safety Notice
•Always replace fuses or circuit breakers with the correct amperage and type.
•Never bypass safety devices.
•Hazardous voltages inside of machine.
•No user serviceable parts inside of machine. Machine should only be
opened by qualified repair personnel.
Punch Capacity
20lb (75 gsm) Copy Paper 20 Sheets
10 Mil (235 gsm) Acetate/PVC Cover 2 Sheets
Binding Capacity
Coil Size Range 6mm - 50mm
Max. Sheet Capacity Range Up to 440 Sheets
Technical Data
Punch Die Pattern 4:1 Oval (4mm x 5mm) .2475" spacing
Paper Size Up to A4 (11.7”) in 1 Pass; Max up to 23.4”
Voltage 115V AC 60Hz
Current 4A
Punch Duty Cycle 2 Min. Run / 1 Min. Rest
Machine weight 76lbs
Dimension (W x D x H) 18.3” x 18” x 12"
