10. Specifications
Characteristics Test Conditions Min. Typical Max. Unit
Physical
Length 101 mm
Width 66 mm
Thickness 13 mm
Weight With battery 90 gm
Functional
ECG Chan
nels Cable selectable 2 2 3 n/a
Accelerometer ±2g/±4g/±8g
Sampling Rate Dynamically selectable 1.56 30 800 Hz
Resolution
Variable 8 12 14 Bits
Memory
Recor
ding Time 30 days
Data Retention microSDHC flash media 10 years
Wireless
Communication Technology UMTS/HSDPA 850/1900
MHz
GSM/GPRS/EDGE 850/900/1800/1900
Time-Slot Class 12 n/a
Output Power
WCDMA Band II & V
0.302
GSM850
2.13
W
P
CS1900
1.74
Electrical
CMRR
90 105 dB
AC Range ±6 mV
DC Range ±300 mV
Input Impedance >10 MOhm
Frequency Response 0.05 to 40 Hz
Recovery Time 1.33 sec
ADC Resolution 12 12 16 Bits
ADC Sample Rate 125 250 1000 Hz
Battery
Type Replicable, externally re-
chargeable Li-Ion
3.7 V
Life From full charge 72 hours
Storage Temperature < 30 days -20 50 C
(shipped condition) > 30 days -20 35 C
Relative Humidity 45 85 %
Environmental
Operating Temperature 0 40 C
Storage Temperature -25 70 C
Relative Humidity Non-condensing 23 C 10 93 %
Atmospheric Pressure 700 1060 hPa
