3.3 General Settings for Main Menu
Press “Lock” key on the front panel to enter the main menu. The LCD will display
the following pages where user can configure the parameters for the device:
User can press UP/DOWN buttons to specify menu item, and then press ENTER to
enter the submenus as below:
1) Alarm Status
The alarm indicator will turn on if there is no A/V signals inputting or outputting bit
rate overflows. User then can enter this menu to check the error type.
2) Encode Setting
Under this submenu, the LCD will show “2.1 Input 1”, “2.2 Input 2” and “2.3 ASI”.
Under submenus 2.1 or 2.2, user could set the video/audio encoding format and bit rate
of the program from the HDMI input.
1 Alarm Status
2 Encode Setting
3 Modulate Setting
4 IP Output Setting
5 Network Setting
6 Saving Config
7 Loading Config
8 Version
2.1 Input 1
2.2 Input 2
2.3 ASI
2.1 Input 1
2.1.1 Program 1
2.1.2 Program 2
To Next Page
