3. Internal tray
Copied/printed paper and fax messages are delivered here.
Rear and left view
CMR634
1
1. Ventilation holes
Prevent overheating.
Guide to Components
(mainly Asia)
• Do not obstruct the ventilation holes by placing objects near them or leaning things against them. If
the machine overheats, a fault might occur.
Front and right view
CMR601
1
7
8
11
9
10
12
2
3
4
5
6
13
