2. Handset
Used as a receiver when a fax unit is installed.
3. Small size paper tray
Holds small size sheets of paper or envelopes.
To use the small size paper tray, install it in tray 2 or the lower paper trays. The small size paper tray cannot be
installed in the lower paper tray. For details about how to install the small size paper tray, see “Installing the
Small Size Paper Tray”.
4. Lower paper tray
Holds up to 550 sheets of paper.
5. Caster table for lower paper tray
To use the lower paper tray, attach the caster table.
6. Tray 3 (LCT)
Holds up to 2,000 sheets of paper.
7. Large capacity tray (LCT)
Holds up to 1,200 sheets of paper.
8. Lower paper trays
Consists of two paper trays. Holds up to 1,100 sheets of paper. Each paper tray holds 550 sheets.
9. Internal tray 2 (1 bin tray)
If you select this as the output tray, copied/printed paper or fax messages are delivered here face down.
10. Bridge unit
Relays paper to the finisher.
11. Internal shift tray
Sorts and stacks multiple sheets of paper.
12. External tray
If you select this as the output tray, copied/printed paper and fax messages are delivered here face down.
13. Booklet Finisher SR3000
Sorts, stacks, staples, and punches multiple sheets of paper. The saddle stitch function can staple multiple sheets
of paper in the center and fold them into booklets. Consists of the following paper trays:
• Finisher upper tray
• Finisher shift tray
• Finisher booklet tray
14. Finisher SR790
Sorts, stacks, and staples multiple sheets of paper. Consists of the following paper trays:
• Finisher upper tray
• Finisher shift tray
15. Finisher SR3050
Sorts, stacks, and staples multiple sheets of paper.
2. Getting Started
64
