Ricoh Aficio SP 3510DN Product Summary Sheet

www.ricoh
-usa.com I Bringing Ricoh Value to Your Organization
Ricoh technology offers a diverse portfolio of solutions to help your organization stay
competitive and move ahead. Let Ricoh show you how to empower your business to
improve critical processes, keep information secure, ensure compliance and promote
environmental sustainability while reducing the
total cost of ownership.
Ricoh Americas Corporation, 5 Dedrick Place, West Caldwell, NJ 07006
Ricoh
®
and the Ricoh Logo are registered trademarks of Ricoh Company, Ltd.
All other
trademarks are the property of their respective owners. Print speed may be affected by
network, application, or PC performance. Specifications and external appearances are
subject to change without notice. Products are shown with optional features.
SYSTEM SPECIFICATIONS continued
Acceptable Paper Sizes
Standard Tray: 3.9" x 5.8" to 8.5" x 14" (100 x 148 mm to 216 x 356 mm)
Bypass Tray: 3.6" x 5.8" to 8.5" x 14" (90 x 148 mm to 216 x 356 mm)
Optional PFUs: Legal, Letter, Half Letter, A4, A5
When Duplexing: Legal, Letter, A4 (SP 3510DN)
Acceptable Paper Weights
Standard Tray: 14 - 43 lb. Bond / 90 lb. Index (52 - 162 g/m
2
)
Bypass Tray: 14 - 43 lb. Bond / 90 lb. Index (52 - 162 g/m
2
)
Optional PFUs: 16 - 28 lb. Bond (60 - 105 g/m
2
)
When Duplexing: 16 - 28 lb. Bond (60 - 105 g/m
2
) (SP 3510DN)
Power Requirements: 120V, 60Hz
Power Consumption: Maximum: 850 W or less
Energy Saver: 5 W
Energy Star Tier 2 Compliant: SP 3510DN only
PRINT CONTROLLER
CPU: 295 MHz
Memory: 64 MB RAM standard / maximum
Standard Interfaces: 10/100Base-TX Ethernet, USB 2.0 Hi Speed
Printer Languages/Drivers: PCL 6, PostScript 3 emulations
Fonts: PCL/PS: 80 fonts
Network Protocols: TCP/IP, IPP
Supported Environments: Windows XP, Vista, 7, Server 2003, Server 2003/R2, Server 2008, Server 2008/R2
Mac OS X v.10.4+,
Citrix MetaFrame, Presentation Server, XenApp 5.0+
Ricoh UNIX Filter
Software Utilities: Web Image Monitor
Ricoh Universal Printer Driver
Printer Utility for Mac
Printer Driver Packager NX (available 2
nd
Half 2012)
@Remote (limited support)
RICOH AFICIO SP 3500N/SP 3510DN HARDWARE OPTIONS & ACCESSORIES
Item Part #
Aficio SP 3500N Mainframe 406957 30-ppm desktop laser printer
Aficio SP 3510DN Mainframe 406962 30-ppm desktop laser printer with Automatic Duplexing
Paper Feed Unit TK 1080 406496 250-sheet capacity
RICOH AFICIO SP 3500N/SP 3510DN SUPPLIES
Item Part # Yield
Standard Yield All-In-One Print Cartridge 406464 2,500 prints*
High Yield All-In-One Print Cartridge 406989 6,400 prints*
The Ricoh Aficio SP 3500N/SP 3510DN ships with a starter AIO cartridge yielding 1,500 pages*.
All other consumables ship at full yield.
*Declared toner yield values in accordance with ISO/IEC 19752.
Actual yields may vary based on types of images printed and other factors.

Ricoh Aficio SP 3510DN Specifications

General

Color	No
Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	8 s
Print speed (black, normal quality, A4/US Letter)	28 ppm
Printing colors	Black
Maximum duty cycle	35000 pages per month
Number of print cartridges	1
Page description languages	PCL 5e, PCL 6, PostScript 3
Total input capacity	250 sheets
Total output capacity	125 sheets
Maximum input capacity	550 sheets
Maximum print size	210 x 297 mm
Duplex media weight	60 - 105 g/m²
Paper tray media types	Envelopes, Plain paper, Recycled paper
Paper tray media weight	52 - 162 g/m²
ISO A-series sizes (A0...A9)	A4, A5, A6
Maximum ISO A-series paper size	A4
Mobile printing technologies	-
Supported network protocols (IPv4)	TCP/IP, IPP
Standard interfaces	Ethernet, USB 1.1, USB 2.0
Internal memory	64 MB
Maximum internal memory	- MB
Product color	Black, White
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (printing)	880 W
Power consumption (PowerSave)	5 W
Sustainability certificates	ENERGY STAR
Mac operating systems supported	Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion
Server operating systems supported	Windows Server 2003, Windows Server 2003 R2, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 x64
Windows operating systems supported	Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64

Weight and Dimensions

Depth	392 mm
Width	370 mm
Height	262 mm
Weight	12700 g
