Technical Bulletin PAGE: 1/1
Reissued:10-Apr-12
Model: AL-P1 Date: 28-Jun-11 No.: RG179024a
RTB Reissue
The items in bold italics were corrected.
Change/Reason: The illustration shown below was corrected.
- The area enclosed by the red box is the correct outline for P/N G1792211 (index #1).
- The cover marked “[A]” below is included in P/N G1792200 (PCU).
- Cleaning Blade (p/n:D0092351) is not included in Frame:PCU:Upper:Ass'y (p/N:G1792211)
Pg. 28
Subject: Parts catalog correction Prepared by: T.Hirakawa
From: 1st Overseas Tech Support Sec., 1st PQM Dept.
Classification:
Troubleshooting
Mechanical
Paper path
Product Safety
Part information
Electrical
Transmit/receive
Other ( )
Action required
Service manual revision
Retrofit information
Tier 2
[A]
