Ricoh Aficio SP 8200DN Technical Bulletin

Technical Bulletin PAGE: 3/4
Model: AL-P1
Date: 27-Jan-15
No.: RG179026
[1] Variable brake
[A] and [B] are the variable brake.
[2]: One way clutch method
One-way clutch method is before. Ratchet method is after.
One-way clutch method Ratchet method
Action to take on MIF:
Please install a new cleaning unit (p/n: D1294304) when a cleaning web issue occurs,
because individual parts are not compatible due to modification of a frame on the fusing
unit. After that, individual parts can be replaced.
