Ricoh bk5010 Installation Manual

1-8
04 October 2007
BOOKLET MAKER INSTALLATION
[A]
Copier exit tray
1. Make sure that the Exit paper arm is in the upper position [A].
2. Removethenisherexittraybyremovingscrews[B](
x 4).
3. Removetheplasticdeector[C],onthenisherexittray.
[B]
[C]

Ricoh bk5010 Specifications

General

Brand	Ricoh
Model	bk5010
Category	Booklet makers
Language	English
