MO-C1 Training
Slide 131
Bypass Feed Path - 2
The carriage unit makes one
pass over the paper so that
the DRESS sensor can
detect the width of the
paper.
The machine knows the
paper length from the paper
size that the user inputs with
the operation panel.
The user must input the
correct size before using
bypass feed.
Bypass
Sensor
Registration
Standby Position
DRESS
Sensor
The bypass sensor does not detect paper length.
To Next Page
