MO-C1 Training
Slide 27
Right Side View
 The optical cloth holder
[1] holds the accessory
optical cloth [2] which can
be used to clean the
exposure glass.
 The scanner stand [3]
holds the scanner unit
above the main unit.
 The ink collector tank
cover [4] can be opened
and closed to insert and
remove the ink collector
tank [5].
No additional notes
